Acoustic Ceiling Hangers

Type ACH

Designed specifically for applications where audible noise attenuation is of most concern, the ACH offers a low cost alternative to larger more traditional spring and rubber hangers. Primarily used to effectively decouple mass acoustic ceilings from the supporting building structure - thus preventing noise breakout or break-in. The ACH may also be used to reduce noise transmission from air conditioning equipment suspended in the ceiling void.



Features

  • High resilience first grade natural rubber elements with deflections up to 3.5 mm.
  • Available in two sizes for loads from 5 kg to 100 kg.
  • Typical force isolation at maximum load of 40 dB to 46 dB @ 125 Hz.
  • Integral failsafe steel overload washers.
  • Capable of 15° angular misalignment.
  • Can be fitted into a wire tie
  • drop rod or a strut type support to an acoustic ceiling.

Typical Applications

  • Acoustic Ceilings.
  • Pipework.
  • Axial Fans and Fan Coil Units.
  • Ductwork and Attenuators.
  • Air Conditioning Equipment.
